Converting an LSM to a B-Tree and back again

I wonder if it is possible to convert an LSM to a B-Tree. The goal is to do it online and in-place -- so I don't want two copies of the database while the conversion is in progress. I am interested in data structures for data management that adapt dynamically to improve performance and efficiency for a given workload.

Workloads change in the short and long term. I hope that data structures can be adapt to the change and converting between an LSM and a B-Tree is one way to adapt. This is more likely to be useful when the data structure supports some kind of partitioning in the hope that different workloads can be isolated to different partitions -- and then some can use an LSM while others use a B-Tree.

LSM to B-Tree

A B-Tree is one tree. An LSM is a sequence of trees. Each sorted run in the LSM is a tree. With leveled compaction in RocksDB there are a few sorted runs in level 0 (L0) and then one sorted run in each of L1, L2 up to the max level (Lmax).

A B-Tree persists changes by writing back pages -- either in-place or copy-on-write (UiP or CoW). An LSM persists changes by writing and then re-writing rows. I assume that page write back is required if you want to limit the database to one tree and row write back implies there will be more than one tree.

There are two things that must be done online and in-place:

1. Convert the LSM from many trees to one tree
2. Convert from row write back to page write back

Note that my goal has slightly changed. I want to move from an LSM to a data structure with one tree. For the one-tree solution a B-Tree is preferred but not required.

The outline of a solution:

1. Reconfigure the LSM to use 2 levels -- L0 and L1 -- and 3 trees -- memtable, L0, L1.
2. Disable the L0. At this point the LSM has two trees -- memtable and L1.
3. Flush the memtable and merge it into the L1. Now there is one tree.
4. After the flush disable the memtable and switch to a page cache. Changes now require a copy of the L1 block in the page cache that eventually get written back via UiP or CoW.

The outline above doesn't explain how to maintain indexes for the L1. Note that after step 2 there is one tree on disk and the layout isn't that different from the leaf level of a B-Tree. The interior levels of the B-Tree could be created by reading/rewriting the block indexes stored in the SSTs.

B-Tree to LSM

The conversion can also be done in the opposite direction (B-Tree to LSM)

1. Treat the current B-Tree as the max level of the LSM tree. While it might help to flush the page cache I don't think that is required. This is easier to do when your LSM uses a B-Tree per level, as done by WiredTiger.
2. Record new changes for insert, update, delete in a memtable rather than a page cache.
3. When the memtable is full then flush it to create a new tree (sorted run, SST) on disk.
4. Eventually start to do compaction.

Combining tiered and leveled compaction

There are simple optimization problems for LSM tuning. For example use leveled compaction to minimize space amplification and use tiered to minimize write amplification. But there are interesting problems that are harder to solve:

1. maximize throughput given a constraint on write and/or space amplification
2. minimize space and/or write amplification given a constraint on read amplification

To solve the first problem use leveled compaction if it can satisfy the write amp constraint, else use tiered compaction if it can satisfy the space amp constraint, otherwise there is no solution. The lack of a solution might mean the constraints are unreasonable but it can also mean we need to enhance LSM implementations to support more diversity in LSM tree shapes. Even when there is a solution using leveled or tiered compaction there are solutions that would do much better were an LSM to support more varieties of tiered+leveled and leveled-N.

When I mention solved above I leave out that there is more work to find a solution even when tiered or leveled compaction is used. For both there are decisions about the number of levels and per-level fanout. If minimizing write amp is the goal then that is a solved problem. But there are usually more things to consider.

Tiered+leveled

I defined tiered+leveled and leveled-N in a previous post. They occupy the middle ground between tiered and leveled compaction with better read efficiency than tiered and better write efficiency than leveled. They are not supported today by popular LSM implementations but I think they can and should be supported.

While we tend to explain compaction as a property of an LSM tree (all tiered or all leveled) it is really a property of a level of an LSM tree and RocksDB already supports hybrids, combinations of tiered and leveled. For tiered compaction in RocksDB all levels except the largest use tiered. The largest level is usually configured to use leveled to reduce space amp. For leveled compaction in RocksDB all levels except the smallest use leveled and the smallest (L0) uses tiered.

So tiered+leveled isn't new but I think we need more flexibility. When a string of T and L is created from the per-level compaction choices then the regex for the strings that RocksDB supports is T+L or TL+. I want to support T+L+. I don't want to support cases where leveled is used for a smaller level and tiered for a larger level. So I like TTLL but not LTTL. My reasons for not supporting LTTL are:

1. The benefit from tiered is less write amp and is independent of the level on which it is used. The reduction in write amp is the same whether tiered is used for L1, L2 or L3.
2. The cost from tiered is more read and space amp and that is dependent on the level on which it is used. The cost is larger for larger levels. When space amp is 2 more space is wasted on larger levels than smaller levels. More IO read amp is worse for larger levels because they have a lower hit rate than smaller levels and more IO will be done. More IO implies more CPU cost from decompression and the CPU overhead of performing IO.

From above the benefit from using T is the same for all levels but the cost increases for larger levels so when T and L are both used then T (tiered) should be used on the smaller levels and L (leveled) on the larger levels.

Leveled-N

I defined leveled-N in a previous post. Since then a co-worker, Maysam Yabandeh, explained to me that a level that uses leveled-N can also be described as two levels where the smaller uses leveled and the larger uses tiered. So leveled-N might be syntactic sugar in the LSM tree configuration language.

For example with an LSM defined using the triple syntax from here as (compaction type, fanout, runs-per-level) then this is valid: (T,1,8) (T,8,2) (L,8,2) (L,8,1) and has total fanout of 512 (8 * 8 * 8). The third level (L,8,2) uses leveled-N with N=2. Assuming we allow LSM trees where T follows L then the leveled-N level can be replaced with two levels: (L,8,1) (T,1,8). Then the LSM tree is defined as (T,1,8) (T,8,2) (L,8,1) (T,1,8) (L,8,1). These LSM trees have the same total fanout and total read/write/space amp. Compaction from (L,8,1) to (T,1,8) is special. It has zero write amp because it is done by a file move rather than merging/writing data so all that must be updated is LSM metadata to record the move.

So in general I don't support T after L but I do support it in the special case. Of course we can pretend the special case doesn't exist if we use the syntactic sugar provided by leveled-N. But I appreciate that Maysam discovered this.

Minimizing write amplification in an LSM

Write-amplification for an LSM with leveled compaction is minimized when the per-level growth factor (fanout) is the same between all levels. This is a result for an LSM tree using a given number of levels. To find the minimal write-amplification for any number of levels this result can be repeated for 2, 3, 4, ... up to a large value. You might find that a large number of levels is needed to get the least write-amp and that comes at price of more read-amp, as the RUM Conjecture predicts.

In all cases below I assume that compaction into the smallest level (from a write buffer flush) has no write-amp. This is done to reduce the size of this blog post.

tl;dr - for an LSM with L1, L2, L3 and L4 what values for per-level fanout minimizes write-amp when the total fanout is 1000?

• (10, 10, 10) for leveled
• (6.3, 12.6, 12.6) for leveled-N assuming two of the levels have 2 sorted runs
• (>1, >1, >1) for tiered

Minimizing write-amp for leveled compaction

For an LSM with 4 levels (L1, L2, L3, L4) there is a per-level fanout between L1:L2, L2:L3 and L3:L4. Assume this uses classic leveled compaction so the total fanout is size(L4) / size(L1). The product of the per-level fanouts must equal the total fanout. The total write-amp is the sum of the per-level write-amp. I assume that the per-level write amp is the same as the per-level fanout although in practice and in theory it isn't that simple. Lets use a, b and c as the variables for the per-level fanout (write-amp) then the math problem is:

1. minimize a+b+c
2. such that a*b*c=k and a, b, c > 1

While I have been working on my math skills this year they aren't great and corrections are welcome. This is a constrained optimization problem that can be solved using Lagrange Multipliers. From above #1 is the sum of per-level write-amp and #2 means that the product of per-level fanout must equal the total fanout. The last constraint is that a, b and c must (or should) all be > 1.

This result uses Lagrange Multipliers for an LSM tree with 4 levels do there are 3 variables: a, b, c. But the math holds for an LSM tree with fewer levels or with more levels. If there are N levels then there are N-1 variables.

L(a, b, c) = a + b + c - lambda * (a*b*c - k)

dL/da = 1 - lambda * bc

dL/db = 1 - lambda * ac

dL/dc = 1 - lambda * ab

then

lambda = 1/bc = 1/ac = 1/ab
bc == ac == ab

and a == b == c to minimize the sum in #1

I wrote a Python script to discover the (almost) best values and the results match the math above.

Minimizing write-amp for tiered compaction

Assuming you can reason about tiered compaction using the notion of levels then the math changes a bit because the per-level write-amp with tiered equals 1 regardless of the per-level fanout. For tiered with 4 levels and 3 variables the problem is:

1. minimize 1+1+1
2. such that a*b*c = k and a, b, c > 1

Any values for a, b and c are sufficient as long they satisfy the constraints in #2. But it still helps to minimize a+b+c if that is predicts read-amp because a, b and c are also the number of sorted runs in L2, L3 and L4. So my advice is to use a == b == c in most cases.

Minimizing write-amp for leveled-N compaction
I explain leveled-N compaction here and here. It is like leveled compaction but allows a level to have more than one sorted run. This reduces the per-level write-amp at the cost of more read-amp. Sometimes that is a good trade.

The math above can also be used to determine how to configure per-level fanout to minimize write-amp for leveled-N. Assume an LSM tree with 4 levels (L1, L2, L3, L4) and 2 sorted runs in L2 and L3. The problem is:

1. minimize a + b/2 + c/2
2. such that a*b*c = k and a, b, c > 1

For leveled compaction I assume that per-level write-amp is all-size(Ln+1) / all-size(Ln) for compaction from Ln into Ln+1. For leveled-N I assume it is run-size(Ln+1) / all-size(Ln) where all-size is the size of all sorted runs on that level and run-size is the size of one sorted run. The astute reader might notice that all-size(Ln) == run-size(Ln) for traditional leveled. For leveled-N I assume that fanout continues to be run-size(Ln+1) / run-size(Ln).

Therefore with leveled-N the per-level write-amp is b/2 for L2 to L3 and c/2 for L3 to L4 because there are 2 sorted runs in the compaction input (twice as much data) in those cases. Were there 3 sorted runs then the values would be b/3 and c/3.

Lagrange Multipliers can be used to solve this assuming we want to minimize a + b/2 + c/2.

L(a, b, c) = a + b/2 + c/2 - lambda * (a*b*c - k)

dL/da = 1   - lambda * bc

dL/db = 1/2 - lambda * ac

dL/dc = 1/2 - lambda * ab

then

lambda = 1/bc = 1/2ac = 1/2ab
bc == 2ac -> b == 2a
bc == 2ab -> c == 2a
2ac == 2ab -> c == b

and 2a == b == c to minimize the sum

If the total fanout is 1000 then the per-level fanout values that minimize write-amp are 10, 10, 10 for leveled and 6.30, 12.60, 12.60 for this example with leveled-N and can be computed by "bc -l"

# for leveled-N
e(l(1000/4)/3)

6.29960524947436582381

e(l(1000/4)/3) * 2
12.59921049894873164762

# and for leveled
e(l(1000)/3)
9.99999999999999999992

One way to think of this result is that with leveled compaction the goal is to use the same per-level fanout between levels. This also uses the same per-level write-amp between levels because per-level write-amp == the per-level fanout for leveled.

But with leveled-N compaction we need to adjust the per-level fanout for levels to continue to get the same per-level write-amp between levels.

Describing tiered and leveled compaction

This is another attempt by me to define the shape of an LSM tree with more formality and this builds on previous posts here and here. My key point is that compaction is the property of a level in an LSM tree rather than the LSM tree. Some levels can use tiered and others can use leveled. This combination of tiered and leveled is already done in popular LSM implementations but it hasn't been called out as a feature.

Stepped Merge

The Stepped Merge paper might have been the first description of tiered compaction. It is a way to improve B-Tree insert performance. It looked like an LSM tree with a few sorted runs at each level. When a level was full the sorted runs at that level were merged to create a larger sorted run in the next level. The per-level write-amplification was 1 because compaction into level N+1 merged runs from level N but did not read/rewrite a run already on level N+1.

This looks like tiered compaction. However it allows for N sorted runs on the max level which means that space-amplification will be >= N. I assume that is too much for most users of tiered compaction in Cassandra, RocksDB and HBase. But this isn't a problem for Stepped Merge because it is an algorithm for buffering changes to a B-Tree, not for storing the entire database and it doesn't lead to a large space-amp for that workload. Note that the InnoDB change buffer is a B-Tree that buffers changes to other B-Trees for a similar reason.

Compaction per level

I prefer to define compaction as a property of a level in an LSM tree rather than a property of the LSM tree. Unfortunately this can hamper discussion because it takes more time and text to explain compaction per level.

I will start with definitions:

1. When a level is full then compaction is done from it to the next larger level. For now I ignore compaction across many levels, but that is a thing (see "major compaction" in HBase).
2. A sorted run is a sequence of key-value pairs stored in key order. It is stored using 1+ files.
3. A level is tiered when compaction into it doesn't read/rewrite sorted runs already in that level.
4. A level is leveled when compaction into that level reads/rewrites sorted runs already in that level.
5. Levels are full when they have a configurable number of sorted runs. In classic leveled compaction a level has one sorted run. A tiered level is full when it has X sorted runs where X is some value >= 2.
6. leveled-N uses leveled compaction which reads/rewrites an existing sorted run, but it allows N sorted runs (full when runs == N) rather than 1.
7. The per level fanout is size(sorted-run in level N) / size(sorted-run in level N-1)
8. The total fanout is the product of the per level fanouts. When the write buffer is 1G and the database is 1000G then the total fanout must be 1000.
9. The runs-per-level is the number of sorted runs in a level when it is full.
10. The per level write-amplification is the work done to compact from Ln to Ln+1. It is 1 for tiered, all-size(Ln+1) / all-size(Ln) for leveled and run-size(Ln+1) / all-size(Ln) for leveled-N where run-size is the size of a sorted run and all-size is the sum of the sizes of all sorted runs on a level.

A level can be described by a 3-tuple (c, f, r) where c is the type of compaction (T or L for tiered or leveled), f is the fanout and r is the runs-per-level. Unfortunately, now we have made the description of an LSM tree even more complex because there is a 3-tuple per level. For now I don't use 3-tuples to describe the write buffer (memory component). That is a topic for another post. Example 3-tuples include:

• T:1:4 - this is tiered with fanout=1 and runs-per-level=4. It is a common configuration for the RocksDB level 0 (L0) where the fanout is 1 because the compaction input is a write buffer flush so the size of a sorted run in L0 is similar to the size of a full write buffer. For now I ignore that RocksDB can merge write buffers on a flush.
• T:8:8 - this is tiered with fanout=8 and runs-per-level=8. When Ln and Ln+1 both use tiered then runs-per-level in Ln == fanout in Ln+1.
• T:8:4 - this is tiered with fanout=8 and runs-per-level=4. It might be used when the next larger level uses leveled and runs-per-level on this level can be smaller than fanout to reduce read-amp.
• L:10:1 - this is common in RocksDB with leveled compaction, fanout=10 and runs-per-level=1
• L:10:2 - this is leveled-N with runs-per-level=2

Compaction per LSM tree

An LSM tree can be described using the per level 3-tuples from the previous section. The following are examples for popular algorithms.

Classic LSM with total fanout = 1000 is:

• C0 is the write buffer
• C1, C2 and C3 are L:10:1

RocksDB leveled with total fanout = 1000 is:

• L0 is T:1:4
• L1 is L:1:1
• L2, L3, L4 are L:10:1

Stepped Merge with total fanout = 1000 is:

• L1 is T:1:10
• L2, L3, L4 are T:10:10

Tiered in HBase and Cassandra with total fanout = 1000 might be:

• L1 is T:1:10
• L2, L3 are T:10:10
• L4 is L:10:1

Tiered+leveled

Note that some smaller levels using tiered and some larger levels using leveled is done by both RocksDB leveled and Cassandra/HBase tiered. I think both of these are examples of an LSM variant that I call tiered+leveled but I won't ask any of the projects update their docs. My definition of tiered+leveled is the smallest (1 or more) levels use tiered compaction, then 0 or more levels use leveled-N, then the remaining levels use leveled.  When tiered=T, leveled=L and leveled-N=N then the regex for this is T+N*L+.

I don't think it is a good idea for leveled levels to precede tiered levels in tiered+leveled (TTL is OK, LTL is not) but that is a topic for another post.

The largest level should use leveled compaction with runs-per-level=1 to avoid too much space amplification.

LSM trees with tiered+leveled can be described using 3-tuples and the previous section does that but here I provide one for a tree that uses leveled-N for L1 and L2 with total fanout = 1000:

• L0 is T:1:4
• L1 is L:1:2
• L2 is L:10:2
• L3, L4 are L:10:1

And another example to show that tiered levels don't have to use the same fanout or runs-per-level, but runs-per-level for Ln == fanout for Ln+1:

• L0 is T:1:20
• L1 is T:20:10
• L2 is T:10:2
• L3 is L:5:1

Leveled-N

Leveled-N can reduce the per level write-amp at the cost of increasing the per level read-amp.

The regex for an LSM tree that uses leveled-N is N+L+ (see the previous section). The largest level should use leveled compaction with runs-per-level=1 to avoid too much space amplification. An example 3-tuple for leveled-N with fanout=1000 that has runs-per-level=2 for L1 and L2 is:

• L1 is L:10:2
• L2 is L:10:2
• L3 is L:10:1

Transaction Processing in NewSQL

This is a list of references for transaction processing in NewSQL systems. The work is exciting. I don't have much to add and wrote this to avoid losing interesting links. My focus is on OLTP, but some of these systems support more than that.

By NewSQL I mean the following. I am not trying to define "NewSQL" for the world:

1. Support for multiple nodes because the storage/compute on one node isn't sufficient.
2. Support for SQL with ACID transactions. If there are shards then cross-shard operations can be consistent and isolated.
3. Replication does not prevent properties listed above when you are wiling to pay the price in commit overhead. Alas synchronous geo-replication is slow and too-slow commit is another form of downtime. I hope NewSQL systems make this less of a problem (async geo-replication for some or all commits, commutative operations). Contention and conflict are common in OLTP and it is important to understand the minimal time between commits to a single row or the max number of commits/second to a single row.

NewSQL Systems

• MySQL Cluster - this was NewSQL before NewSQL was a thing. There is a nice book that explains the internals. There is a company that uses it to make HDFS better. Cluster seems to be more popular for uses other than web-scale workloads.
• VoltDB - another early NewSQL system that is still getting better. It was after MySQL Cluster but years before Spanner and came out of the H-Store research effort.
• Spanner - XA across-shards, Paxos across replicas, special hardware to reduce clock drift between nodes. Sounds amazing, but this is Google so it just works. See the papers that explain the system and support for SQL. This got the NewSQL movement going.
• CockroachDB - the answer to implementing Spanner without GPS and atomic clocks. From that URL they explain it as "while Spanner always waits after writes, CockroachDB sometimes waits before reads". It uses RocksDB and they help make it better.
• FaunaDB - FaunaDB is inspired by Calvin and Daniel Abadi explains the difference between it and Spanner -- here and here. Abadi is great at explaining distributed systems, see his work on PACELC (and the pdf). A key part of Calvin is that "Calvin uses preprocessing to order transactions. All transactions are inserted into a distributed, replicated log before being processed." This approach might limit the peak TPS on a large cluster, but I assume that doesn't matter for a large fraction of the market.
• YugaByte - another user of RocksDB. There is much discussion about it in the recent Abadi post. Their docs are amazing -- slides, transaction IO path, single-shard write IO path, distributed ACID and single-row ACID.
• TiDB - I don't know much about it but they are growing fast and are part of the MySQL community. It uses RocksDB (I shouldn't have forgotten that).

Other relevant systems

• FoundationDB - I am curious where this goes given the competition explained above.
• Aurora - not NewSQL yet because this doesn't scale across nodes. It does support large nodes and that might be sufficient for a large part of the market. But Amazon moves fast (see the new parallel query feature) so I wouldn't be surprised if this became NewSQL one day. I appreciate that they have begun to explain the internals -- here and here.
• MongoDB - not SQL, but starting to get interesting with the new features for read and write concerns. There is also new support for causal consistency and retryable writes.
• Clustrix - a NewSQL system that is now part of MariaDB. Maybe this becomes open source.
• Kudu - awesome paper, interesting research on HybridTime, useful docs on the internals.
• Vitess - was created to scale MySQL for Youtube. Now is part of CNCF, backed by a startup and used by many companies. Cross-shard writes are atomic, but isolation is weaker.
• Splice Machine  - SQL on HBase. Summary is "100% ACID via snapshot isolation with optimistic concurrency via write-write conflicts" and details are here. Has integration to use Spark for OLAP, so this is HTAP.

Durability debt

I define durability debt to be the amount of work that can be done to persist changes that have been applied to a database. Dirty pages must be written back for a b-tree. Compaction must be done for an LSM. Durability debt has IO and CPU components. The common IO overhead is from writing something back to the database. The common CPU overhead is from computing a checksum and optionally from compressing data.

From an incremental perspective (pending work per modified row) an LSM usually has less IO and more CPU durability debt than a B-Tree. From an absolute perspective the maximum durability debt can be much larger for an LSM than a B-Tree which is one reason why tuning can be more challenging for an LSM than a B-Tree.

In this post by LSM I mean LSM with leveled compaction.

B-Tree

The maximum durability debt for a B-Tree is limited by the size of the buffer pool. If the buffer pool has N pages then there will be at most N dirty pages to write back. If the buffer pool is 100G then there will be at most 100G to write back. The IO is more random or less random depending on whether the B-Tree is update-in-place, copy-on-write random or copy-on-write sequential. I prefer to describe this as small writes (page at a time) or large writes (many pages grouped into a larger block) rather than random or sequential. InnoDB uses small writes and WiredTiger uses larger writes. The distinction between small writes and large writes is more important with disks than with SSD.

There is a small CPU overhead from computing the per-page checksum prior to write back. There can be a larger CPU overhead from compressing the page. Compression isn't popular with InnoDB but is popular with WiredTiger.

There can be an additional IO overhead when torn-write protection is enabled as provided by the InnoDB double write buffer.

LSM

The durability debt for an LSM is the work required to compact all data into the max level (Lmax). A byte in the write buffer causes more debt than a byte in the L1 because more work is needed to move the byte from the write buffer to Lmax than from L1 to Lmax.

The maximum durability debt for an LSM is limited by the size of the storage device. Users can configure RocksDB such that the level 0 (L0) is huge. Assume that the database needs 1T of storage were it compacted into one sorted run and the write-amplification to move data from the L0 to the max level (Lmax) is 30. Then the maximum durability debt is 30 * sizeof(L0). The L0 is usually configured to be <= 1G in which case the durability debt from the L0 is <= 30G. But were the L0 configured to be <= 1T then the debt from it could grow to 30T.

I use the notion of per-level write-amp to explain durability debt in an LSM. Per-level write-amp is defined in the next section. Per-level write-amp is a proxy for all of the work done by compaction, not just the data to be written. When the per-level write-amp is X then for compaction from Ln to Ln+1 for every key-value pair from Ln there are ~X key-value pairs from Ln+1 for which work is done including:

• Read from Ln+1. If Ln is a small level then the data is likely to be in the LSM block cache or OS page cache. Otherwise it is read from storage. Some reads will be cached, all writes go to storage. So the write rate to storage is > the read rate from storage.
• The key-value pairs are decompressed if the level is compressed for each block not in the LSM block cache.
• The key-value pairs from Ln+1 are merged with Ln. Note that this is a merge, not a merge sort because the inputs are ordered. The number of comparisons might be less than you expect because one iterator is ~X times larger than the other and there are optimizations for that.

The output from the merge is then compressed and written back to Ln+1. Some of the work above (reads, decompression) are also done for Ln but most of the work comes from Ln+1 because it is many times larger than Ln. I stated above that an LSM usually has more IO and less CPU durability debt per modified row. The extra CPU overheads come from decompression and the merge. I am not sure whether to count the compression overhead as extra.

Assuming the per-level growth factor is 10 and f is 0.7 (see below) then the per-level write-amp is 7 for L1 and larger levels. If sizeof(L1) == sizeof(L0) then the per-level write-amp is 2 for the L0. And the per-level write-amp is always 1 for the write buffer.

From this we can estimate the pending write-amp for data at any level in the LSM tree.

1. Key-value pairs in the write buffer have the most pending write-amp. Key-value pairs in the max level (L5 in this case) have none. Key-value pairs in the write buffer are further from the max level.
2. Starting with the L2 there is more durability debt from a full Ln+1 than a full Ln -- while there is more pending write-amp for Ln, there is more data in Ln+1.
3. Were I given the choice of L1, L2, L3 and L4 when first placing a write in the LSM tree then I would choose L4 as that has the least pending write-amp.
4. Were I to choose to make one level 10% larger then I prefer to do that for a smaller level given the values in the rel size X pend column.

legend:

w-amp per-lvl   : per-level write-amp

w-amp pend      : write-amp to move byte to Lmax from this level

rel size        : size of level relative to write buffer

rel size X pend : write-amp to move all data from that level to Lmax

        w-amp   w-amp   rel     rel size

level   per-lvl pend    size    X pend

-----   ------- -----   -----   --------

wbuf    1       31          1      31

L0      2       30          4     120

L1      7       28          4     112

L2      7       21         40     840

L3      7       14        400    5600

L4      7       7        4000   28000

L5      0       0       40000       0

Per-level write-amp in an LSM

The per-level write-amplification is the work required to move data between adjacent levels. The per-level write-amp for the write buffer is 1 because a write buffer flush creates a new SST in L0 without reading/re-writing an SST already in L0.

I assume that any key in Ln is already in Ln+1 so that merging Ln into Ln+1 does not make Ln+1 larger. This isn't true in real life, but this is a model.

The per-level write-amp for Ln is approximately sizeof(Ln+1) / sizeof(Ln). For n=0 this is 2 with a typical RocksDB configuration. For n>0 this is the per-level growth factor and the default is 10 in RocksDB. Assume that the per-level growth factor is equal to X, in reality the per-level write-amp is f*X rather than X where f ~= 0.7. See this excellent paper or examine the compaction IO stats from a production RocksDB instance. Too many excellent conference papers assume it is X rather than f*X in practice.

The per-level write-amp for Lmax is 0 because compaction stops at Lmax.

Bloom filter and cuckoo filter

The multi-level cuckoo filter (MLCF) in SlimDB builds on the cuckoo filter (CF) so I read the cuckoo filter paper. The big deal about the cuckoo filter is that it supports delete and a bloom filter does not. As far as I know the MLCF is updated when sorted runs arrive and depart a level -- so delete is required. A bloom filter in an LSM is per sorted run and delete is not required because the filter is created when the sorted run is written and dropped when the sorted run is unlinked.

I learned of the blocked bloom filter from the cuckoo filter paper (see here or here). RocksDB uses this but I didn't know it had a name. The benefit of it is to reduce the number of cache misses per probe. I was curious about the cost and while the math is complicated, the paper estimates a 10% increase on the false positive rate for a bloom filter with 8 bits/key and a 512-bit block which is similar to a typical setup for RocksDB.

Space Efficiency

I am always interested in things that use less space for filters and block indexes with an LSM so I spent time reading the paper. It is a great paper and I hope that more people read it. The cuckoo filter (CF) paper claims better space-efficiency than a bloom filter and the claim is repeated in the SlimDB paper as:

However, by selecting an appropriate fingerprint size f and bucket size b, it can be shown that the cuckoo filter is more space-efficient than the Bloom filter when the target false positive rate is smaller than 3%

The tl;dr for me is that the space savings from a cuckoo filter is significant when the false positive rate (FPR) is sufficiently small. But when the target FPR is 1% then a cuckoo filter uses about the same amount of space as a bloom filter.

The paper has a lot of interesting math that I was able to follow. It provides formulas for the number of bits/key for a bloom filter, cuckoo filter and semisorted cuckoo filter. The semisorted filter uses 1 less bit/key than a regular cuckoo filter. The formulas assuming E is the target false positive rate, b=4, and A is the load factor:

• bloom filter: ceil(1.44 * log2(1/E))
• cuckoo filter: ceil(log2(1/E) + log2(2b)) / A == (log2(1/E) + 3) / A
• semisorted cuckoo filter: ceil(log2(1/E) + 2) / A

The target load factor is 0.95 (A = 0.95) and that comes at a cost in CPU overhead when creating the CF. Assuming A=0.95 then a bloom filter uses 10 bits/key, a cuckoo filter uses 10.53 and a semisorted cuckoo filter uses 9.47. So the cuckoo filter uses either 5% more or 5% less space than a bloom filter when the target FPR is 1% which is a different perspective from the quote I listed above. Perhaps my math is wrong and I am happy for an astute reader to explain that.

When the target FPR rate is 0.1% then a bloom filter uses 15 bits/key, a cuckoo filter uses 13.7 and a semisorted cuckoo filter uses 12.7. The savings from a cuckoo filter are larger here but the common configuration for a bloom filter in an LSM has been to target a 1% FPR. I won't claim that we have proven that FPR=1% is the best rate and recent research on Monkey has shown that we can do better when allocating space to bloom filters.

The first graph shows the number of bits/key as a function of the FPR for a bloom filter (BF) and cuckoo filter (CF). The second graph shows the ratio for bits/key from BF versus bits/key from CF. The results for semisorted CF, which uses 1 less bit/key, are not included.  For the second graph a CF uses less space than a BF when the value is greater than one. The graph covers FPR from 0.00001 to 0.09 which is 0.001% to 9%. R code to generate the graphs is here.

CPU Efficiency

From the paper there is more detail on CPU efficiency in table 3, figure 5 and figure 7. Table 3 has the speed to create a filter, but the filter is much larger (192MB) than a typical per-run filter with an LSM and there will be more memory system stalls in that case. Regardless the blocked bloom filter has the least CPU overhead during construction.

Figure 5 shows the lookup performance as a function of the hit rate. Fortunately performance doesn't vary much with the hit rate. The cuckoo filter is faster than the blocked bloom filter and the block bloom filter is faster than the semisorted cuckoo filter.

Figure 7 shows the insert performance as a function of the cuckoo filter load factor. The CPU overhead per insert grows significantly when the load factor exceeds 80%.
